JP-8 Fuel Additive Injection System MIL-DTL-83133 SDA / CI /FSII
JP-8 Fuel Additive Injection System turns Jet-A Fuel into Military Approved Jet-A fuel with additives aka JP-8 Fuel. Our system blends Corrosive Inhibitor CI, Fuel System Icing Inhibitor FSII, and Static Dissipative Additive SDA into Jet-A fuel, making it military compliant.
These systems help the US Military buy Jet-A fuel to save on fuel costs for the American Taxpayer: https://www.cnbc.com/2014/11/19/us-air-force-completes-jet-fuel-conversion-impacts-entire-jet-fuel-market.html
Additive Injection System for SDA, FSII and Lubricity Improver Brochure: AI-JP-8 Brochure-R1
General Features of the D-2 Injection Systems
- Real Time Control of Neat Additive injection for SDA, CI, or FSII. Modular design allows for all three additives or any combination in the same cost effective package.
- Ensures your facility is meeting the MIL- DTD-83133 specification for Static Dissipative Additive (SDA) / Corrosion Inhibitor (CI) and Fuel System Icing Inhibitor (FSII).
- Someone can tie directly the system into a DCS system such as “Top Tech” or “Guardian” fuel terminal management software. Allows for standard terminal operator oversight. As required, BOL printed results.
- Uses only NEAT Additive for injection, eliminating the need for additive dilution and mixing prior to injection. Full mass flow real time control based on product line flow rate.
- Full documentation package provided with every skid, including PI&D’s, foundation, sensor /injector mounts, installation/check off manual, user manual, and AB Studio 5000 PLC Source Code. See example drawings on page 4.
- Full Stainless Steel System, weather protected pumps built to your custom site specifications, results in low-cost installation combined with low long-term maintenance costs.
Additional Benefits of the D-2 Fuel Additive Injection Systems…
- Modular all Stainless Additive storage tanks provided maintain additive supplied with visual level and optional low level alarms connected directly to terminal systems to further prevent run dry incidents.
- Fully ATEX or FM/ FMc Certified for Hazardous Zone Environments.
- Optional In Line Conductivity Sensor JF-1A is ASTM D2624 Listed and ATEX/ FM Certified. Optional Item for real time monitoring of conductivity.
- Custom injection nozzle prevent idle time flow out and ensure well mixed additive/product.
- D-2 Inc. fully supports every system and provides a 1 year limited warranty from date of install, can provide on-site commissioning.
- D-2 Inc. is a highly experienced firm with multiple AI-1 injection systems operating globally with a perfect track record.
